Feature

■ Compact structure、Easy to carry, Designed for first aid、Transit design

■ Ventilation modes and parameters can be set to facilitate

■ Airway pressure waveform and a variety of parameter monitoring, Intuitive monitoring patients with state

■ Offers three power: AC、Car Power、Built-in battery

■ With skirting, Convenient ambulances and transit beds use

Main unit

■ High-definition LCD display

■ Application: Adult and Child(Does not apply to baby)

■ Pneumatic power control

■ Respiratory modes: A/C、A/C+SIGH、SIMV、SPONT、Manual

■ Tidal volume: 0～1500mL

■ FiO2: 48%～100%

■ PTRIG: -2～0KPa

■ Alarm Mute: ≤120s

■ Plimit-H: 2～6KPa

■ Plimit-L: 0～2KPa

■ PEEP: 0.5～2KPa,(Optional)

■ Power supply: AC100～240V±10%, 50/60Hz±1%

Monitoring parameters

Tidal volume、MV、fTOT、PPEAK、Airway pressure waveform、Trigger instructions、AC-powered instructions、DC power supply instructions、Charging indicator, etc

Alarm parameters

Plimit-H、Plimit-L、Choke、VT-Low、LPO、Power and low
